型号
|
Model
|
|
QBA
|
特性
Identification
|
驱动方式Drive type
|
电动(蓄电池)battery
|
驾驶方式 Operation type
|
站驾Standing
|
额定载荷Load capacity
|
Q(kg)
|
2000
|
载荷中心距Load center
|
c(mm)
|
600
|
前悬距Center of drive axle to fork
|
x(mm)
|
800
|
轮距Wheelbase
|
y(mm)
|
1310/1360
|
重量weight
|
自重(带电瓶)Weight with battery
|
kg
|
700
|
尺寸
Wheels chassis
|
起升高度Lifting height
|
h 3(mm)
|
120
|
降低时高度Lowered height
|
h 13(mm)
|
85
|
总体长度Overall length
|
l 1(mm)
|
1850/1900
|
货叉尺寸Fork dimensions
|
s/e/l(mm)
|
55x185x1150(1200)
|
货叉外宽Distance between fork-arms
|
b 5(mm)
|
540/685
|
叉腿离地间隙
Ground Clearance,center of wheelbase
|
m2(mm)
|
30
|
通道宽度，托盘1000x1200
Aisle width for pallets 1000X1200 crossways
|
Ast(mm)
|
2380
|
转弯半径Turning radius
|
Wa(mm)
|
1520
|
车体宽度Overall Width
|
b1(mm)
|
780
|
通道宽度，托盘800x1200Aisle width for pallets 800X1200 lengthways
|
Ast(mm)
|
2260
|
轮子,底盘
Wheels,Chassis
|
轮子 Wheel
|
|
聚胺酯轮polyurethane
|
轮子尺寸,前轮Wheel Size, Front Wheel
|
mm
|
￠250x75
|
轮子尺寸,后轮Wheel Size, Rear Wheel
|
mm
|
￠80x80
|
附加轮（尺寸）Additional wheel
|
mm
|
￠115x50
|
轮,前后数量（x=驱动轮）
Wheel numbers(x=drive wheel)
|
|
1x+2/4
|
平衡轮轮距Thread,Front
|
b10(mm)
|
560
|
后轮轮距Thread,Rear
|
b11(mm)
|
355/500
|
性能数据
Performance
|
行驶速度,满载、空载
Travel Speed,laden/unladen
|
Km/h
|
5/6
|
提升速度,满载/空载
Lift Speed,laden/unladen
|
m/s
|
0.06/0.08
|
下降速度,满载/空载
Lower Speed,laden/unladen
|
m/s
|
0.05/0.06
|
爬坡能力,装载/卸载
Max.G radient Performance, laden/unladen
|
%
|
8/10
|
行车制动 Service Brake
|
电磁制动 Electromagnetic
|
电动机
Motor
|
驱动电机功率Drive motor power
|
KW
|
1.5
|
提升电机功率Lifting motor power
|
KW
|
2.0
|
蓄电池电压/额定容量
Battery Voltage/nominal capacity
|
V/Ah
|
24/210(280)
|
蓄电池重量 Battery Weight
|
Kg
|
210/280
|
蓄电池尺寸（长x宽x高）
Battery Size(Lenght X Width X Height)
|
mm
|
650x245(520)
|
驾驶员耳边噪音等级符合DIN12053
Sound level at driver‘s ear acc.to DIN12053
|
dB(A)
|
70
|
